Matrice 600 review

Matrice 600 – Let’s Get Our Hands On It

Today I am working with the DJI Matrice 600 platform which is clearly one of the largest DJI drones to date. After using it for a while, I wanted to put together a full Matrice 600 review and tell you all you need to know before purchasing it. So what really stands out about the Matrice 600 is really the ultimate blend of all of DJI’s best technologies. Let’s go over some of the features that really make the Matrice 600 unique and then we’ll go into what’s included in the package. I think you have a pretty good idea at the end of this article what to expect on with this platform and why it’s really going to become the new standard for commercial and Industrial applications.

If you’re seeking to capture professional theatre grade aerial photos, DJI’s self-proclaimed first heavy lifter, the Matrice 600, maybe the next drone on your radar. The M600 is a hexacopter designed for filmmakers and other industry specialists looking to capture another cinematic masterpiece. Although Matrice 600 trumps other drones in conditions of size, it was created to be in the same way easy to create and fly.

matrice 600 design
DJI Matrice 600 – image credit: Dronenerds.com

Matrice 600 Design and Performance

Ready to create and be used in minutes, the Matrice 600 is suitable for maximum toughness and easy maintenance. The M600 features a lightweight aluminum body, manually retracting landing legs and foldable carbon fiber forearms. The retractable getting gear means that the thighs won’t arrive in the video footage, as the foldable carbon fiber arms provide extra stableness and portability. The Matrice’s six propellers are also carbon fiber reinforced which make them extra stiff.

The DJI Matrice 600 was created with six rotors for extra balance and redundancy. It also includes six battery packs for a protracted flight time and further security in the air. Together with the Zenmuse X5 or XT camera, the M600 has an air travel time as high as 35 minutes, and with the Ronin-MX or a bulkier payload, an air travel time of around 16 minutes.

The M600 is with the capacity of hauling a payload as high as 13.2 pounds and works with challenging DJI Zenmuse type of camcorders and gimbals. The M600 also includes the A3 air travel control system, which can be upgraded to the A3 Pro controller. Completely customizable and made with every one of the latest solutions, the Matrice 600 is a robust system that gives as it pertains to shooting video footage worth the silver screen.

Another key good thing about the Matrice 600’s design is its unlimited customization options. Most of DJI’s type of gimbals and cams are reinforced by the M600 system. Thus giving operators the best freedom to customize the M600 to match their exact needs.

With regards to cruising through the environment, the M600 is very continuous yet agile, specifically for its size. The utmost speed of the Matrice 600 is 40,2 miler per hour. The M600 can soar at a maximum altitude of 2500 meters above sea level. The M600 also offers a maximum ascent time of 5 miles per hour and a maximum descent time of 3 miles per hour.

M600 Controller

Complete and correct control is what you would get with the Matrice 600. The M600 includes the brand new A3 airfare controller as well as the Lightbridge 2 system. The Lightbridge 2 system can stream long range 1080p live footage and help dual video insight and dual operator setups, one for air travel and one for camera control.

The A3 trip controller has built-in failsafe actions for lack of signal, low vitality and even propulsion inability as high as three motors. In case of a propulsion inability, the drone yaws consistently and the A3 automatically switches to Home-lock for getting the aircraft properly if an emergency situation appears. The user can also choose to update to the A3 Pro version that can be increased with 2 additional IMUs and Gps unit products for triple redundancy and much more accuracy.

Furthermore, users can buy the D-RTK GNSS system, which owns centimeter level position accuracy and reliability and can tolerate interference from metal objects.

The Matrice 600 supports the DJI Assistant 2 and the DJI Go software. The iPhone app gives users an integral trip simulator, HD view, electric battery level position, redundancy status, transmitting strength, and even more. With the software and the simplified Lightbridge 2 Universal remote Controller, flying a huge, heavy lifting drone hasn’t been easier. Users can also control camera options including shutter acceleration, ISO, focus, and aperture. The DJI Assistant 2 makes firmware posts and configuration a cinch and also offers a built-in airline flight simulator. Gleam new Ground Stop software in the works for collaborative jobs with multiple Matrice 600 aircraft.

dji a3 flight controller
DJI A3 flight controller – image credit: spreadingwingsstore.com

Matrice 600 Specs

Reading the specification sheet for the Matrice 600 can be an overpowering experience, but some of the numbers do stand out.

The full total takeoff weight is no more than 34.3 pounds. Because of the nude drone weights 13.2 pounds significantly less than that, you have a broad range of payload options. That is a great choice if you are buying a commercial drone that can do some heavy lifting.

She’ll do 40 miles per hour in quiet condition and endure winds as fast as 18 miles per hour. That is a higher altitude drone, with the typical propellers the service roof is 8200 feet (2500m) above sea level. Utilize the model 2195 props which climb to a nosebleed-worthy 14 800 feet (4500m).

Retractable equipment is standard, which is good because at the expert level it absolutely must be. There is no chance that getting gear will ruin your perfect shot. The utmost transmitting range is 2.2 miles (3.5km), considering that you have a type of sight.

The six rotors have motors that are positively cooled, this means less downtime between plane tickets.

The real superstar of the show is, however, the A3 Expert flight controller. That is a triple-redundant (effectively sextuple redundant with analytical technology) self-monitoring airline flight system. It’s a good adaptive brain that may also securely land a drone when you yourself have propulsion failing on some rotors.

Matrice 600 Battery

Power supply technology remains the Achilles’ heel of electric UAVs and unless they invent electric battery technology with significantly higher energy densities, that isn’t going to improve drastically soon. So we can not expect the Matrice 600 to work wonders with the regulations of physics.

Not surprisingly, the Matrice has impressive strength. The TB47S power supply packs a wholesome 4500 mAh. You can even find the uprated TB48S to press more air travel time but at hook weight penalty.

Corresponding to DJI’s public statistics, the stock battery pack will get you merely over thirty minutes of trip time with the lightest payload but attach the high-end RED camera installation and you will be seeking to land in about a quarter-hour.

This is an extended air travel time given how much weight the 600 can take and the packages are quick to swap out. You get size TB47S items in the pack and a charger with the capacity of juicing all of them at the same time. It requires about 90 minutes to totally charge the power supply, therefore you get between 90 minutes and 3 times of flight time for each and every full six-battery fee.

Matrice 600 Propellers

You will find two propeller options incorporated with the Matrice Expert. The typical foldable 2170R propellers that can operate up to 2500m ASL are 21-inch carbon amalgamated items. They cost $39 per set to replace and undoubtedly, you will need three pairs for an entire refit.

Additionally, there is the 21-in. 2195 propellers that ought to only be utilized above 2500m ASL unless you want to risk motor damage. They are a significant $59 per set, although most people won’t use them.

Matrice 600 Gimbal and Camera

Although Matrice 600 doesn’t feature a gimbal itself, it offers operators the possibility to choose the exact gimbal they need for his or her drone. The amount of gimbal and camera options on the Matrice Expert 600 is one of the very most impressive reasons for having this machine. The Matrice officially facilitates six different Zenmuse gimbal setups and two Ronin-MX setups for you can attach something similar to the RED EPIC or Hasselblad A5D.

Blended, the Matrice 600 and the Ronin-MX make an unstoppable pairing. The Ronin-MX is constructed of aluminum, can change 360 levels, and can support any camera. The Ronin-MX is also with the capacity of attaching to the Matrice 600’s Global positioning system as well as the Lightbridge 2 system.

The Matrice 600 will not feature a camera but be using its heavy lifting capacities, users can pick from a wider selection of cameras to photograph with. The M600 works with the complete Zenmuse line, like the RED EPIC. While using Zenmuse XT and X5, the M600 can soar for about 35 minutes. With any much larger camera, the Matrice can stay static in the air for about 16 minutes. The Matrice 600 is also appropriate for any other alternative party cameras.

dji matrice 600 ronin mx
DJI Matrice 600 and Ronin-MX – image credit: aerialmediapros.com

DJI Matrice 600 Price

There is no way to sugar-coat it. The Matrice 600 Pro costs around $4999. A huge lump of change so you haven’t even bought a gimbal or camera yet. Certainly, you can obtain it on “easy” conditions at $440 per month, but this is plainly a UAV designed for assignments with big finances in Hollywood and professional contexts.

Is it a good price? Considering that there are incredibly few drones that will haul a RED camera into the sky for you, it’s hard to be too severe for the price.



Summary of M600

The Matrice 600 was created to supply the operator independence to choose just what kind of gimbal, camera, and accessories they would like to use for the video footage they envision, without having to be limited to one camera or one system.

The big good thing about the M600 is its capacity to carry heavy camcorders and accessories while still retaining balance and steadiness in the air. Another reward would be that the Matrice 600’s system can seamlessly combine with DJI’s full selection of Zenmuse gimbals and surveillance cameras. The Matrice 600’s six rotors and battery power are a spotlight of its design, presenting users added basic safety in air travel along with a protracted air travel time. The upgradable A3 system is also a nothing you’ve seen prior seen feature adding extra accuracy and reliability, reliability, and perfection to the machine.

Overall, the DJI Matrice 600 is a deserving update from the Spreading Wings series and DJI has once more showcased why they outpace their competition.



DJI Matrice 600 – What’s in the box

M600 drone

2 power cables

2 charging hubs

2 battery chargers

DJI Hex charger

Battery stickers

6 intelligent flight batteries (TB47S)

Double-sided tape

A remote controller

Micro-USB cradle

Travel case

dji matrice 600 in the box
DJI Matrice 600 What’s In The Box

FRAME

Diagonal Wheelbase1133 mm
Aircraft Dimensions
  • 1668 mm x 1518 mm x 759 mm (Propellers, frame arms and GPS mount unfolded)
  • 640 mm x 582 mm x 623 mm (Frame arms and GPS mount folded)
Package Dimensions620 mm x 320 mm x 505 mm
Intelligent Flight Battery Quantity6
Weight (with six TB47S batteries)9.1 kg
Weight (with six TB48S batteries)9.6 kg
Max Takeoff Weight15.1 kg

CHARGER

ModelA14-100P1A
Voltage Output26.3 V
Power Rating100 W

GIMBALS

Supported DJI GimbalsZenmuse X3; Zenmuse X5 series; Zenmuse XT; Ronin-MX; Zenmuse Z15 series HD gimbals: Z15-A7, Z15-BMPCC, Z15-5D III, Z15-GH4
Retractable Landing GearStandard
Operating Temperature14° to 104° F (-10° to 40° C)

PERFORMANCE

Hovering Accuracy (P-Mode, with GPS)Vertical: ±0.5 m, Horizontal: ±1.5 m
Max Angular VelocityPitch: 300°/s, Yaw: 150°/s
Max Pitch Angle25°
Max Speed of Ascent5 m/s
Max Speed of Descent3 m/s
Max Wind Resistance8 m/s
Max Flight Altitude above Sea Level2500 m
Max Speed18 m/s (No wind)
Hovering Time (with six TB47S batteries)*No payload: 35 min, 6 kg payload: 16 min
Hovering Time (with six TB48S batteries)*No payload: 40 min, 5.5 kg payload: 18 min
* The hovering time is based on flying at 10 m above sea level in a no-wind environment and landing with 10% battery level.
